AVDT-BOB

Description

The AVDT-BOB is a compact Dante break out box with embedded Digital Signal Processing. The AVDT-BOB has state-of-the-art analog microphone preamplifiers for a very high audio dynamic and quality over Dante at a very contained price:

* There is a minimum order quantity (MOQ) for the products "AVDT-BOB-AS8io" and "AVDT-BOB-ADX8io."

• 4 Dante inputs named “Dante In1” up to “Dante In4” are coming from Dante network via the Gigabit Ethernet Main or Aux ports.
• 2 to 4 analog Mic/Line inputs named “Mic/Line1”, “Mic/Line2”.. are coming from the Mic/Line In connectors
• 2 to 4 analog Line outputs named as “Out1”, “Out2″… are connected to Line Out connectors.
• 60dB gain in 3dB steps with Equivalent Noise (EIN) as low as -123dBu.
• AES/EBU stereo input/output on Euroblock (-ADE- versions) or on SUBD25 (-ADX- versions).

The AVDT-BOB has a DSP to process and mix audio signal at the source and at the output. The AVDT-BOB features a dual core ARM processor associated with a large amount of flash memory for a universal and multiplatform remote control over IP (iOS, Android, Windows, Mac OS, Linux).

They provide to the AVDT-BOB a powerful processing with an efficient, easy and smart remote control:

• Smart embedded DSP for advanced internal audio mixing and effect processing
• 4 independent mixers of the 6x to 8x inputs
• 8 equalizations and 8 limiters compressors
• Build-in dual ARM RISC processor with Web 2.0 HTML5 interface
• Direct remote without any installation via Mac OSX, Windows, and Linux computer or via iPad, iPhone or Tablet,Smartphone
